Waverider 1060

The GEMINI WR 1060 is the latest edition and currently the biggest in the Waverider Series of RIBS. Also known locally as the ‘Beast’, the WR 1060 is truly remarkable.

This large, versatile and extremely powerful hull builds on the spirit of the ‘go-anywhere’ Waverider 730 & 850, designed and built to thrive in the harshest conditions.

The space, sea-keeping comfort and long range make this GEMINI ideal for offshore Rescue, Military, Commercial, or the serious high-end Leisure user.

Category:
Share this:

Standard Features

  • Hypalon tubes (Military Grade 1670Dtex)
  • 2 x Heavy duty shark fin rubbing strakes
  • Full length grab line
  • 7 x Inflation Valves
  • 7 x Over pressure release valves
  • Internally taped seams
  • 2 x Paddles
  • 2 x Stainless steel bow eyes
  • Anchor rope bow protection
  • Anchor locker
  • Aluminium keel protection
  • 3 x Transom knees
  • Engine motor well
  • Under deck cable track
  • 2 x Below deck fuel lockers
  • 2 x Towing points
  • Self-draining deck
  • Non-slip deck
  • 1 x Double action pump
  • 1 x Repair kit

Technical Specifications

WR 1060
LENGTH OVERALL (LOA) 10.6M
INTERNAL LENGTH (MOTOR WELL TO ANCHOR LOCKER) 7.4
BEAM OVERALL 3.25
BEAM INTERNAL 1.95
TUBE DIAMETER 600
TUBE VOLUME 7.225
NO. OF TUBE COMPARTMENTS 7
INFLATION PRESSURE 0.25BAR
WEIGHT EMPTY 1350
MAX WEIGHT 5000
MAX PERSONS 22
MAX LOAD 3650
REC HP/ (KW) 500
MAX HP/ (KW) (ISO6185-4) 600
MAX ENGINE WEIGHT AS PER SAMSA BOUYANCY CERTIFICATE (KILOGRAMS) 760
TRANSOM HEIGHT - SINGLE ENGINE INSTALLATION U:30"(762)
- TWIN ENGINE INSTALLATION X:25"(648)
ACTUAL
HULL DEADRISE (DEGREES) 20
MAX FUEL CAPACITY (LITRES) 1080

Related products

DISCLAIMER: Whilst every attempt has been made by GEMINI to give accurate information, all data provided by GEMINI is intended for guidelines only. Engine size, weight and propeller selection can affect a boat’s performance and/or regulatory compliance. Regulations pertaining to maximum passengers, payload and permissible engine power and other rules differ from country to country , it is a customer’s own responsibility to comply with their own local regulations at all times. GEMINI reserves the right to amend specifications and technical data or withdraw product without prior notice.
