Dive 470 & 530

The GEMINI DIVE 470 & DIVE 530 Inflatable range of boats are of a more conventional shape and are built with the purpose to carry maximum loads.

Both these models have very large buoyancy tubes allowing divers / crew and their equipment to be transported with ease.

They are used commercially by a variety of speciality operators and on expeditions around the world.

Category:
Share this:

Standard Features

  • Heavy-duty shark fin rubbing strake
  • Anti-hogging strip
  • Self-draining deck
  • Large flat deck area
  • Internally taped seams
  • 2 x Paddles & paddle straps
  • 2 x Towing /tie-down points
  • Non-slip deck
  • Righting rope & pouch
  • 5 x Inflation Valves
  • 4 x Carry handles
  • 1 x Double action pump
  • 1 x Repair kit


Technical Specifications

DIVE 470
LENGTH OVERALL (LOA) 470
INTERNAL LENGTH (MOTOR WELL TO ANCHOR LOCKER) 3.4m
BEAM OVERALL 2.12
BEAM INTERNAL 1.01
TUBE DIAMETER 530
TUBE VOLUME 1.928
NO. OF TUBE COMPARTMENTS 5
INFLATION PRESSURE 0.25bar
WEIGHT EMPTY 150
MAX WEIGHT 900
MAX PERSONS 6
MAX LOAD 750
REC HP/ (KW) 60
MAX HP/ (KW) ISO 6185-3 60
MAX ENGINE WEIGHT AS PER SAMSA BOUYANCY CERTIFICATE (KILOGRAMS) 120
TRANSOM HEIGHT - SINGLE ENGINE INSTALLATION S: 15"(381)
- TWIN ENGINE INSTALLATION NA
ACTUAL
HULL DEADRISE (DEGREES) NA
MAX FUEL CAPACITY (LITRES) 2 x 25L
DIVE 530
LENGTH OVERALL (LOA) 530
INTERNAL LENGTH (MOTOR WELL TO ANCHOR LOCKER) 4m
BEAM OVERALL 2.12
BEAM INTERNAL 10.1
TUBE DIAMETER 530
TUBE VOLUME 2.2
NO. OF TUBE COMPARTMENTS 5
INFLATION PRESSURE 0.25bar
WEIGHT EMPTY 170
MAX WEIGHT 1000
MAX PERSONS 8
MAX LOAD 830
REC HP/ (KW) 60
MAX HP/ (KW) ISO 6185-3 60
MAX ENGINE WEIGHT AS PER SAMSA BOUYANCY CERTIFICATE (KILOGRAMS) 120
TRANSOM HEIGHT - SINGLE ENGINE INSTALLATION S: 15"(381)
- TWIN ENGINE INSTALLATION NA
ACTUAL
HULL DEADRISE (DEGREES) NA
MAX FUEL CAPACITY (LITRES) 2 x 25L

Related products

DISCLAIMER: Whilst every attempt has been made by GEMINI to give accurate information, all data provided by GEMINI is intended for guidelines only. Engine size, weight and propeller selection can affect a boat’s performance and/or regulatory compliance. Regulations pertaining to maximum passengers, payload and permissible engine power and other rules differ from country to country , it is a customer’s own responsibility to comply with their own local regulations at all times. GEMINI reserves the right to amend specifications and technical data or withdraw product without prior notice.
