Standard Features
|
Waverider 550
The rugged GEMINI Waverider 550 was designed to withstand the harshest of weather conditions.
These mid-sized models in the Gemini range of RIBS are not only used commercially, but also for rescue & military operations internationally.
The Legendary WR 550 is the most in use Rescue RIB along the African coast.
The majority of the National Sea Rescue institute’s fleet is made up of GEMINI WR 550’s.
Share this:
Technical Specifications
| WR 550 | |
|---|---|
| LENGTH OVERALL (LOA) | 5.5M |
| INTERNAL LENGTH (MOTOR WELL TO ANCHOR LOCKER) | 3.3M |
| BEAM OVERALL | 2.3M |
| BEAM INTERNAL | 1.2M |
| TUBE DIAMETER | 480 |
| TUBE VOLUME | 1.935 |
| NO. OF TUBE COMPARTMENTS | 5 |
| INFLATION PRESSURE | 0.25BAR |
| WEIGHT EMPTY | 350 |
| MAX WEIGHT | 1451 |
| MAX PERSONS | 10 |
| MAX LOAD | 1101 |
| REC HP/ (KW) | 100 |
| MAX HP/ (KW) ISO 6185-3 | 120 |
| MAX ENGINE WEIGHT AS PER SAMSA BOUYANCY CERTIFICATE (KILOGRAMS) | 240 |
| TRANSOM HEIGHT - SINGLE ENGINE INSTALLATION | L: 20"(508) |
| - TWIN ENGINE INSTALLATION | S: 20"(508) |
| ACTUAL | |
| HULL DEADRISE (DEGREES) | 20 |
| MAX FUEL CAPACITY (LITRES) | 130 |
Related products
DISCLAIMER: Whilst every attempt has been made by GEMINI to give accurate information, all data provided by GEMINI is intended for guidelines only. Engine size, weight and propeller selection can affect a boat’s performance and/or regulatory compliance. Regulations pertaining to maximum passengers, payload and permissible engine power and other rules differ from country to country , it is a customer’s own responsibility to comply with their own local regulations at all times. GEMINI reserves the right to amend specifications and technical data or withdraw product without prior notice.
